An ice machine fails quietly. The bin empties over a busy evening and the operator finds out when there is no ice. A controller on the machine reports the bin, the water supply and the compressor load, so your service network hears about it first.
The bin level over a day shows whether production matches use. A bin that never recovers after the evening is a machine that is too small or one that is making less than it should.
A machine with no water makes no ice, and a blocked filter looks the same from the front. Inlet pressure separates a supply problem from a machine problem before anyone drives to site.
Run hours from the compressor current let cleaning and filter changes follow actual use and not the calendar.
A starting list, not a fixed kit. The ports are set from the dashboard, so the same controller takes a different mix of sensors on a different model.
| Signal | How it is read | What it tells you |
|---|---|---|
| Bin level | Level sensor in the bin, RS485 or analogue | Whether production is keeping up with use |
| Water inlet pressure | Analogue pressure transducer | Supply faults and blocked filters |
| Compressor current | Clamp-on current sensor over RS485 | Run hours and cycling |
| Condenser air temperature | 1-Wire or PT1000 probe | A blocked condenser or a plant room that is too hot |
| Power state | Supply sense on a digital input | Outages, and machines switched off overnight |
Four ports on one controller, and RS485 devices share a bus, so most of this list fits on a single unit.
One machine reporting is a gadget. Every machine you have shipped reporting to the same place is a service business.
Each machine reports to the same cloud. Your service desk sees which units are running, which are in alarm and which have gone quiet, before the customer calls.
Accounts nest: you sit above your dealers, and each dealer above its customers. A parent account cannot grant more than it holds, and a unit can be shared with a service company without handing over a login.
Readings and events are stored with their time and export to Excel, for a warranty claim, a service report or a disagreement about what happened and when.
A REST API with scoped tokens covers what the dashboard covers, so fleet data can feed your service system, your ERP or your customer portal directly.
The controller takes 6 to 32 V DC, so it runs from a 12 or 24 V supply already on the machine. Its internal rechargeable battery keeps it reporting after the machine loses power, which is when the reading matters most.
It connects over 4G-LTE from wherever the machine is installed. There are no Wi-Fi credentials to collect and no IT department to convince at each customer.
If the machine already has a controller with an RS485 Modbus RTU port, give us its register map and we add it as a supported device. Its values and alarms then arrive alongside the sensor readings.
The web dashboard is served on your domain with your name, logo and colours, and the iOS and Android apps are published under your own developer accounts. Your customers log in to your product.
Readings are held on the device while the network is down and sent in order when it returns, so the record has no gap where the incident was.
Yes. Compressor run time is recorded from the current sensor, so cleaning and filter changes can be planned from hours run. The figures export to Excel or go to your service system through the API.
Yes. The controller reports over 4G-LTE, so it does not depend on the site network at all.
Either. Every controller comes with OmniCloud included, and the REST API does what the dashboard does if you would rather build your own front end on top of it.
The supply voltage available on the machine, the signals you want reported, the register map if the machine has a Modbus controller, and how your dealers and customers should be separated. A first batch on machines already in the field is the usual way to begin.
Over the air, by cellular. Where there is no network at all, the unit raises its own Wi-Fi access point and takes the update from a phone or laptop beside it.
What it is, what you want it to report, and who needs to see which units. We come back with how the controller wires in and how the accounts would be laid out.
